Somta Series 177 – HSS-Co Split Point Straight Shank Cobalt Jobber Drill 2.00mm

Somta Series 177 - HSS Co5 Standard Point Heavy Duty Jobber Drills 2mm

£4.00

Somta Series 177 - HSS Co5 Standard Point Heavy Duty Jobber Drills 2mm

£4.00

HSS-Co Split Point Straight Shank Cobalt Jobber Drill 2.00mm – Somta Series 177

The SOMTA 1770200 – 2.00 mm HSS-Co Cobalt Jobber Drill Bit is a high-performance tool engineered for tough materials and high-heat applications. Manufactured to DIN 338 standards, it features a 118° split-point for precise, self-centering starts and a 30° right-hand spiral for efficient chip evacuation. Constructed from high-speed steel with 5% cobalt (HSS-Co) and finished in gold oxide, this bit offers superior hardness, red hardness retention, and tool life—ideal for stainless steel, alloyed steels, and abrasive metals.

Key Features Benefits

  • 118° Split Point Tip – Enables easy starts and reduces walking, even on hard surfaces.
  • Right-Hand Spiral, 30° Helix Angle – Ensures smooth chip removal and stable cutting performance.
  • HSS-Co (Cobalt Alloy) – 5% cobalt enhances heat resistance and hardness for demanding drilling jobs.
  • Gold Oxide Finish – Improves oxidation resistance and wear visibility under high temperatures.
  • DIN 338 Jobber-Length Standard – Offers a balance of rigidity and reach for precision drilling.
  • Straight Full-Diameter Shank – Ensures proper alignment and secure chuck grip.
  • High-Temperature Drilling – Ideal for stainless steel, titanium, and other hard-to-machine metals.

Technical Specifications

  • Part No: 1770200
  • Cutting Diameter: 2.00 mm
  • Flute Length: 24 mm
  • Overall Length: 49 mm
  • Point Angle: 118°, Split-Point
  • Helix Angle: 30°, Right-Hand Spiral
  • Shank: Straight, Full 2.00 mm Diameter
  • Material & Finish: High-Speed Steel with 5% Cobalt (HSS-Co), Gold Oxide Finish
  • Tolerance: H8
  • Standard: DIN 338 (Jobber-Length)

Why Choose the SOMTA 1770200 Cobalt Jobber Drill?

  • Designed for Hard Metals – Built for stainless steel, castings, high-tensile steels, and more.
  • Superior Heat Resistance – Cobalt alloy construction prevents edge breakdown at elevated temperatures.
  • Accurate Micro Drilling – Reliable 2.00 mm bit for electronics, tooling, and fine metalwork.
  • Proven Industrial Performance – Trusted by professionals for its durability and precision.

The SOMTA 1770200 2.00 mm cobalt jobber drill with gold oxide finish combines accuracy, toughness, and heat resistance—making it ideal for applications requiring long-lasting performance in hard or heat-treated materials.
