10pc Kyocera CNMG120408PS CA525 – Turning Insert (Finishing to Medium, PS Chipbreaker)

Kyocera CNMG120408PS CA525 – Turning Insert (10 pcs Finishing to Medium, PS Chipbreaker) The Kyocera CNMG120408PS CA525 is a reliable negative-type rhombic turning insert designed for finishing to medium cutting...
£70.00
£0.00
£70.00
(-0%)
SKU: CNMG120408PSCA525-10
Availability: In Stock
Subtotal: £70.00
10pc Kyocera CNMG120408PS CA525 – Turning Insert (Finishing to Medium, PS Chipbreaker)

10pc Kyocera CNMG120408PS CA525 – Turning Insert (Finishing to Medium, PS Chipbreaker)

£0.00 £70.00

10pc Kyocera CNMG120408PS CA525 – Turning Insert (Finishing to Medium, PS Chipbreaker)

£0.00 £70.00

Kyocera CNMG120408PS CA525 – Turning Insert (10 pcs Finishing to Medium, PS Chipbreaker)

The Kyocera CNMG120408PS CA525 is a reliable negative-type rhombic turning insert designed for finishing to medium cutting operations in steels. It utilizes Kyocera’s proven PS chipbreaker, which ensures stable chip control, smooth evacuation, and reduced cutting resistance across a wide range of machining conditions. Combined with the CA525 CVD-coated carbide grade, this insert delivers excellent wear resistance, toughness, and long tool life, making it ideal for both continuous and light interrupted cutting in steel applications.

Key Features & Benefits

  • CA525 Grade: Advanced CVD-coated carbide optimized for steel turning with superior wear and heat resistance.
  • PS Chipbreaker: Provides smooth chip evacuation and stable performance in finishing to medium cutting ranges.
  • High Edge Strength: Ensures reliable performance in both stable and slightly interrupted cuts.
  • Excellent Surface Finish: Minimizes vibration and cutting force, achieving consistent, high-quality results.
  • Versatile Application: Suitable for general-purpose turning of carbon steels, alloy steels, and mild steels.

Technical Specifications

  • Designation / Order Code: CNMG120408PS CA525
  • Insert Shape: 80° Rhombic (C Type, Negative)
  • Insert Type: Double-Sided Negative Turning Insert
  • Material: CVD-Coated Carbide
  • Grade: CA525 – Steel Turning Grade
  • Chipbreaker: PS – Finishing to Medium Range
  • Inscribed Circle (IC): 12.70 mm
  • Thickness (S): 4.76 mm
  • Hole Diameter (D1): 5.16 mm
  • Corner Radius (RE): 0.8 mm
  • Relief Angle: 0° (Negative Type)
  • Cutting Depth (ap): 0.2 – 3.0 mm
  • Feed Rate (f): 0.10 – 0.45 mm/rev
  • Tolerance (Class M): ±0.025 mm (thickness) / ±0.13 mm (corner height)
  • Pack Quantity: 10 pcs

About Kyocera CA525:
Kyocera’s CA525 CVD-coated carbide grade is engineered for stability and durability in steel turning. It offers a balanced combination of hardness and fracture toughness, maintaining cutting edge stability and long tool life even under demanding conditions. The strong adhesion and optimized coating layer provide excellent resistance to wear and heat, ensuring reliable machining performance in both finishing and medium turning operations.
